THREE - Cores cables
With water blocking technology, copper or aluminium conductor, XLPE Insulated, Copper wire & tape screened, double steel tapes armoured, and PVC sheathed

Specification:
SPLN 43-5-4

Rated Voltage:
6/10 kV (12kV)
8.7/15 kV (17.5 kV)
12/20 kV (24 kV)

Application:
Suitable for Distribution Indoor and Outdoor Installation, direct burial or on Trays

1. Conductor                   : Copper or Aluminium (Compact Circular Stranded)

2. Conductor Screen      : Extruded Semiconductive Compound

3. Insulation                    : Extruded Crosslinked Polyethylene (XLPE)

4. Insulation Screen       : Extruded Strippable Semiconductive Compound

5. Water Blocking           : Helicaly Overlapped Semiconductive Water Blocking Tape

6. Metalic Screen           : Copper wire & Tape

7. Water Blocking           : Helicaly Overlapped Non-conductive Water Blocking Tape

8. Inner Sheath              : Extruded PVC 90⁰C

9. Armour                       : Helicaly Overlapped Galvanized Steel Tape (Double Tape)

10. Outer Sheath           : Extruded PVC 90⁰C

Identification of core by binder tape :
Red Yellow Black

Special Features on Request:
• Tinned Copper Wire
• Heat Resistant
• Oil Resistant
• Flame Retardant Cat. A. B. or C
• Flame Retardant Non Category
• Nylon Coated
• Anti Termite
• Anti Rodent
• PVC Low Smoke Low Halogen
• Low Smoke Zero Halogen
