N2XSERY
Specification:
IEC 60502-2, SNI IEC 60502-2, BS 7835
Rated Voltage:
3.6/6 kV (7.2kV) 12/20 kV (24 kV)
6/10 kV (12kV) 18/30 kV (36 kV)
8.7/15 kV (17.5 kV)
Application:
Suitable for Distribution Indoor and Outdoor Installation, direct burial or on Trays
Construction :
1. Conductor : Copper or Aluminium (Compact
Circular Stranded)
2. Conductor Screen : Extruded Semiconductive Compound
3. Insulation : Extruded Crosslinked Polyethylene
(XLPE)
4. Insulation Screen : Extruded Strippable Semiconductive
Compound
5.Metalic Screen : Helicaly Overlapped Copper Tape
6. Filler : Non Hygroscopic Material
7. Inner Sheath : Extruded PVC 900C
8. Armour : Galvanized Steel Wire
9. Outer Sheath : Extruded PVC 900C
Identification of core by binder tape :
Brown, Black, Grey or by request
