N2XSY
SINGLE - CORE CABLE
With Water Blocking Technology, Copper or Aluminium Conductor, XLPE Insulated, Copper Wire & Tape Screened, and
PVC Sheathed
Specification:
SPLN 43-5-3
Rated Voltage :
3.6/6 kV (7,2 kV)
6/10 kV (12 kV)
8.7/15 kV (17.5 kV)
12/20 kV (24 kV)
Application:
Suitable for distribution indoor and outdoor installation, in conduit, throughs or on trays
1. Conductor : Copper or Aluminium (Compact Circular Stranded)
2. Conductor Screen : Extruded Semiconductive Compound
3. Insulation : Extruded Crosslinked Polyethylene (XLPE)
4. Insulation Screen : Extruded Strippable Semiconductive Compound
5. Water Blocking : Helicaly Overlapped Semiconductive Water Blocking Tape
6. Metalic Screen : Copper Wire & Tape
7. Water Blocking : Helicaly Overlapped Non-Conductive Water Blocking Tape
8. Sheath : Extruded PVC 900C
Special Features on Request:
• Tinned Copper Wire
• Heat Resistant
• Oil Resistant
• Flame Retardant Cat. A. B. or C
• Flame Retardant Non Category
• Nylon Coated
• Anti Termite
• Anti Rodent
• PVC Low Smoke Low Halogen
• Low Smoke Zero Halogen
