NYMHY

NYMHY

Identification of Cores :

Twin-Cores : Light-Blue, Black
Three-Cores

: System I
  Green with yellow stripe ( G/Y ), Blue, Brown

  System O
  Brown, Black, Grey
Four-Cores

: System I
  Green with yellow stripe ( G/Y ), Brown, Black, Grey

  System O
  Blue, Brown, Black, Grey
Five-Cores

  : System I
    Green with yellow stripe ( G/Y ), Blue, Brown, Black, Grey

    System O
    Blue, Brown, Black, Grey, Black



Construction :


Flexible Copper Conductor
Extruded PVC Insulated
Extruded PVC Outer Sheathed


Symbol    :    NYMHY



Size Ranged  :    2 x 0.75 ... 2.5mm²
     3 x 0.75 ... 2.5mm²
     4 x 0.75 ... 2.5mm²
     5 x 0.75 ... 2.5mm²
Applicable Standard :  Rated Voltage: 300/500 Volt
Specification :  SPLN 42-6-2-1991
   SNI 04-6629.5 2006
   IEC 60227-5 IEC
   Other Specification are available on request
Application

: Indoor location connection or portable application
